DISPLAX ARA Box Specifications

DISPLAX ARA Box Specifications

Overview

The Ara Box is a light, compact, and cost-effective Google certified device with Ethernet or wireless connection (2.4 and 5 GHz), shipped with Android 10 - very popular for digital signage and also supports interactive touch functionality. With Android OS, it is possible to install apps from Google Play Store, and APKs. The most popular deployments are in Retail, Interactive Digital Signage, and Entertainment.
It is also possible to fine-tune the touch performance of a connected DISPLAX Skin via DISPLAX Connect for Android, available here: DISPLAX Connect 3.10.0

Download Specifications File

Key Features

  1. Easy setup - Plug & Play
  2. Application Autostart built-in
  3. Allows screen rotation for Portrait or Landscape oriented displays
  4. Multi-Touch functionality supported
  5. Ethernet & WiFi 2.4/5 GHz connection
  6. USB 2.0 & 3.0
  7. Bluetooth
  8. High efficiency heat dissipation

Physical Specifications


Hardware

Dimensions/Weight

Size
109x109x18mm
Weight
100g
Package Size/Weight
202x127x55mm/300g


External/Ports

The physical box is designed with heat dissipation for improved performance, and the inputs consist of:
  1. AV Stereo Jack port
  2. Optical Digital Audio port
  3. LAN port (also has WiFi functionality)
  4. HDMI port
  5. DC Power Supply port (can also be powered via USB)
  6. USB 2.0 port
  7. USB 3.0
  8. Micro SD Card slot

Internal

COMPONENT / FEATURE
Description
CPU
Rockchip RK3318 64-bit quad-core ARM Cortex-A53 @ 1.5 GHz
GPU
ARM G31
OS
Android 10.1
Support Decoder format
HW UHD 4K H.265 60fps 10-bit video decoder & low latency
1080p H.265/H.264 60fps encoder VP9
Profile-2 up to 4Kx2K@60fps
H.265 HEVC MP-10@L5.1 up to 4Kx2K@60fps AVS2-P2 Profile up to 4Kx2K@60fps
H.264 AVC HP@L5.1 up to 4Kx2K@30fps
H.264 MVC up to 1080P@60fps
MPEG-4 ASP@L5 up to 1080P@60fp (ISO-14496)
WMV/VC-1 SP/MP/AP up to 1080P@60fps
AVS-P16(AVS+) /AVS-P2 JiZhun Profile up to 1080P@60fps MPEG-2 MP/HL up to 1080P@60fps (ISO-13818)
MPEG-1 MP/HL up to 1080P@60fps (ISO-11172)
RealVideo 8/9/10 up to 1080P@60fps
Multiple language and multiple format sub-title video support
MJPEG and JPEG unlimited pixel resolution decoding (ISO/IEC-10918) Supports JPEG thumbnail, scaling, rotation and transition effects
Supports *.mkv,*.wmv,*.mpg, *.mpeg, *.dat, *.avi, *.mov, *.iso, *.mp4, *.rm and *.jpg file formats
Support Media Format
Avi/Ts/MP4/Mkv/Mov/ISO/RM/MOV/Flv/Dat/mpg/mpeg
Support Music Format
MP3/WMA/AAC/WAV/OGG/DDP/HD/FLAC/APE
Support Photo Format
HD JPEG/BMP/GIF/PNG/TIFF
HDR
HDR10 and HLG
HDD File System
FAT16/FAT32/NTFS
High Definition Video Output
4K (3840×2160 pixel)
OSD Languages
26 International languages
Mouse/Keyboard
Support for mouse and keyboard via USB; Support wireless mouse and keyboard via 2.4GHz USB dongle
LAN
Standard 10/100M
HDMI
Built-in HDMI 2.1 transmitter including both controller and PHY with CEC, Dynamic HDR
Remote Control
Infra Red (IR) Remote Control
AV
Supported
Optical
Supported
Bluetooth
Supported
USB Host
1 x High speed USB 3.0;  1 x USB 2.0
Card Reader
1 x TF Card up to 64GB; Supports SDHC/SDXC
DC
∮4.0 x 1.7 mm DC 5V@2A

Accessories

  1. Power adapter
  2. HDMI cable (1m)
  3. IR Remote Control
  4. User Manual
