Touch Controller Safety Instructions
The product contains electronics, which are electrically sensitive. Please take the necessary precautions when using such devices.
• Select a suitable workspace
• Avoid carpets in cool, dry areas
• When you work on a carpet where static electricity is likely to be generated, make sure to take anti-static measures beforehand
• Hold any component by its edge to avoid touching any terminals or parts
• Store or carry any component in an anti-static bag
• Do not disassemble parts other than as specified in the procedure
• Take care when connecting or disconnecting cables. A damaged cable can cause a short in the electrical circuit
• When installing a Flexible Flat Cable, route the cable so it is not pinched by other components and is clear of the system unit cover
• Align connector pins when connecting the flexible flat cable - misaligned connector pins may cause mechanical damage to system components
• Always release the strain-relief loop on the connector pins first before disconnecting the flexible flat cable
