ACTION | WINDOWS | MacOS |
Show/Hide Help | F1 | F1 |
Full Screen | F11 | Alt+F11 |
Show/Hide Toolbars | H | H |
Toggle Stand-by | Alt+S | Alt+S |
Change frame view color | Alt+B | Alt+B |
Enable/Disable capture frame view | Alt+F | Alt+F |
Enable/Disable capture touches view | Alt+T | Alt+T |
Select next Touch Controller | Tab | Tab |
Change tab | Alt+, | Alt+, |
Show/Hide Touch Controller settings | S | S |
Enable/Disable Touch | E | E |
Screen number calibration | Keys [1..n] (screen number) | Keys [1..n] (screen number) |
Restart Touch Controller | R | R |
Increase Gain | PageUp | PageUp |
Decrease Gain | PageDown | PageDown |
Increase Threshold | + | + |
Decrease Threshold | – | – |
Sensor tools | T | T |
Enable/Disable Palm Rejection | P | P |
Increase Palm area | Ctrl+P | Cmd+P |
Decrease Palm area | Ctrl+O | Cmd+O |
Enable/Disable Shield | X | X |
Increase Shield | Ctrl+X | Cmd+X |
Decrease Shield | Ctrl+Z | Cmd+Z |
Load Settings | Ctrl+L | Cmd+L |
Save Settings | Ctrl+S | Cmd+S |
Load Firmware file | W | W |
Touch Test | C | C |
Show/Hide TUIO Toolbar | Alt+O | Alt+O |
Show/Hide Security Pin | Alt+P | Alt+P |
Quit | Ctrl+Q | Cmd+Q |
